Optimizing the Image
Versana Essential – User Guide 2-11
5759238-100 English Rev. 2
Easy 3D Mode (Option)
Acquiring a 3D Scan
1. Optimize the B-Mode image. Ensure even gel coverage.
2. Press the User Defined key configured for 3D functionality.
Two screens appear.
NOTE: Before scanning, set appropriate values for Acq Mode, Scan
Plane and the Scan distance.
3. To start acquiring the image, press L (the left split screen
key).
4. To perform a parallel scan, scan evenly. To perform a sweep
(fan) scan, rock the probe once. Note the distance of the
scan.
5. The 3D volume of interest (VOI) is dynamically assembled
on the right side of the screen.
NOTE: If the image stops before you’re done scanning, start
acquiring the 3D volume of interest again.
6. To complete the 3D scan, press R (the right split screen
key).
NOTE: You can also press Freeze, but then you need to also press
the 3D key to obtain the final rendering images.
Table 2-5: 3D Package Options
3D Type Description
Sensor/No
Sensor
Available Tabs
Easy 3D Mode Designed for rendering B Mode images,
e.g., fetal face scans.
No sensor 3D Acquisition, Easy
Mode, Movie
