IRECTION GB091046, REVISION 2 VIVID E9 / VIVID E7 BT’13 SERVICE MANUAL
Chapter 10 - Care & maintenance 10 - 11
10-5-4-2 Air Filter cleaning
The VIVID E9 / VIVID E7 has two air filters, one at the rear (Rear Air Filter) and one below the Card
Rack (Bottom Filter).
Two bottom filters have been used:
• “nylon strip” Bottom Filter (units manufactured before November 2010)
• “handle type” Bottom Filter (introduced November 2010)
Please refer to the respective air filter replacement and cleaning instructions:
• 8-8-2 "Rear Filter and “handle type” Bottom Filter replacement" on page 8-176
or
• 8-8-3 "Rear Air Filter replacement" on page 8-180
• 8-8-4 "Bottom “nylon strip” Air Filter replacement" on page 8-182
Lock the wheels before removing/cleaning the air filters. This prevents the Ultrasound system
from moving unexpectedly.
DO NOT operate the unit without the air filters in place.
