Chapter 4 - Functional Checks 4-15
4-5-2-3 Load only parts of the “Complete Backup”
NOTE: Following procedure should be used, if the user has saved own 2D/3D/4D Programs or AutoText
entries, but new presets have to be added to match the installed Application Software version (e.g., 2D/
3D/4D Programs for new probe, etc.).
1.) Perform Preparations on page 4-13.
2.) Click the +
sign (next to “Complete Backup”) to open the content tree.
3.) For example: Click the +
sign and copy the desired content by clicking the >> button; and so on
NOTE: To return selected items from the “Load Data” field to “Backup Data” field select the <<
button.
4.) Confirm selection with the LOAD
button.
Settings will be loaded and the US Application Software restarts.
Figure 4-14 Load image settings for probe (e.g., RAB4-8-D)
copy desired
content into
right field
[+] sign
>>
button
[Load] button
