3 Description
3.1 Design of the valve
Fig.4: Main components on the valve
Key
No. Designation
1 Seal ring
2 Bearing
9 Lantern
15 Valve disk
20 Handwheel
21 Switching disk
28 Clamp
31 Housing
Description
Design of the valve
430BAL008583EN_1
12.08.2019 15
