GEA VARIVENT Series User Manual

Dimensions for tubes in Inch OD
Inch OD
Outside
diameter
Wall
thickness
Inside
diameter
Outside
diameter acc.
to BS 4825
1" 25.4 1.65 22.1 x
1.5" 38.1 1.65 34.8 x
2" 50.8 1.65 47.5 x
2.5" 63.5 1.65 60.2 x
3" 76.2 1.65 72.9 x
4" 101.6 2.11 97.38 x
6" 152.4 2.77 146.86 x
Dimensions for tubes in Inch IPS
Inch IPS
Outside
diameter
Wall
thickness
Inside
diameter
Outside
diameter
according to
DIN EN ISO
1127
2" 60.3 2 56.3 x
3" 88.9 2.3 84.3 x
4" 114.3 2.3 109.7 x
6" 168.3 2.77 162.76 x
5.5 Lubricants
Lubricants
Designation Material no.
Rivolta F.L.G. MD-2 413-071
PARALIQ GTE 703 413-064
Technical data
Lubricants
430BAL008583EN_1
20 12.08.2019

GEA VARIVENT Series Specifications

General

Series	VARIVENT
Actuation	Pneumatic
Connection Types	Clamp, weld end, threaded, flange
Application	Food, beverage, dairy, pharmaceutical, and chemical industries
Standards	EHEDG, FDA, 3-A
Materials	Stainless steel
