5 Technical data
5.1 Type plate
The type plate clearly identifies the valve.
Fig.5: Type plate
The type plate provides the following key data:
Key data of the valve
Type Control valve type I
Serial Serial number
Material 1.4404 (AISI316L) / EPDM (FDA)
Control air pressure bar/psi max. 8.0 / 116
Product pressure bar/psi 5.0 / 72.5
5.2 Technical data
Refer to the following tables for the key technical data of the valve:
Technical data: Valve
Designation Description
Size
DN 10 to DN 125
1" to 4" OD
2" to 6" IPS
Material of product contact parts Stainless steel 1.4404
Fitting position Vertical
Technical data: Ambient temperatures
Designation Description
Max. temperature PTFE O-ring (7)
material no. 930-464
during flaming + 150 °C (302 °F)
Ambient temperature 0 to 60 °C (32 ... 148 °F), standard
Product temperature and operating
temperature
depending on the sealing material
Technical data
Type plate
430BAL008583EN_1
12.08.2019 17

GEA VARIVENT Series Specifications

General

Series	VARIVENT
Actuation	Pneumatic
Connection Types	Clamp, weld end, threaded, flange
Application	Food, beverage, dairy, pharmaceutical, and chemical industries
Standards	EHEDG, FDA, 3-A
Materials	Stainless steel
