Seals for sampling valve I
Item Qty Designation Material DN 10/15 DN 25
1"
DN 40-150
1.5" - 6"
1 1 Seal ring Ø 13 13 13
EPDM 924-255 924-255 924-255
FKM 924-297 924-297 924-297
HNBR 924-312 924-312 924-312
5 2 O-ring Ø -- 42 x 3 60 x 3
EPDM -- 930-309 930-144
FKM -- 930-168 930-171
HNBR -- 930-632 930-633
7 1 O-ring Ø 4.5 x 3 4.5 x 3 4.5 x 3
PTFE 930-464 930-464 930-464
22 1 O-ring Ø 36 x 3 36 x 3 36 x 3
NBR 930-050 930-050 930-0520
23 1 O-ring Ø 11 x 3 11 x 3 11 x 3
NBR 930-010 930-010 930-010
24 1 Quad ring Ø 10.2 x 2.62 10.2 x 2.62 10.2 x 2.62
NBR 930-466 930-466 930-466
Set of seals cpl. EPDM 221-004744 221-004747 221-004750
FKM 221-004745 221-004748 221-004751
HNBR 221-004746 221-004749 221-004752
Grease RIVOLTA F.L.G. MD-2 100g tube not included in the set of seals 413-136
Storage instructions: storage in accordance with DIN 7716
relative humidity approx. 65%, temperature 15-25°C and protected from light
When replacing seals, observe the instructions in the instruction manual!
429-046
Parts list - sampling valve I
430BAL008583EN_1
44 12.08.2019
