Gecko Aeware Swim spa solution - Connections; Low Level Configuration Selection Chart

18
Swim Spa Solution™
Config. # P1
P2
P3 P4 P5 BL CP configuration Ozone configuration Filter Type
Heater
Pump
Connection
Diagram
1 2sp 1sp 1sp 1sp -- -- --- On during Filter cycle, with P1 Clean, P1L P1 Page: 19
2 2sp 1sp 1sp 1sp -- X --- On during Filter cycle, with P1 Clean, P1L P1 Page: 20
3 2sp 2sp 1sp 1sp -- -- --- On during Filter cycle, with P1 Clean, P1L P1 Page: 19
4 2sp 2sp 1sp 1sp -- X --- On during Filter cycle, with P1 Clean, P1L P1 Page: 20
5 2sp 1sp 1sp 1sp X -- --- On during Filter cycle, with P1 Clean, P1L P1 Page: 21
6 2sp 1sp 1sp 1sp X X --- On during Filter cycle, with P1 Clean, P1L P1 Page: 22
7 2sp 1sp 1sp -- -- -- --- On during Filter cycle, with P1 Clean, P1L P1 Page: 23
Low Level Configuration Selection Chart
Note: Every OEM has its own preset configurations.
The Low level configuration may differ depending on the manufacturer.
connections
