41
Swim Spa Solution™
heat.wav ratings
Voltage: 240 VAC, 60 Hz
Current: 17 A resistive (4 kW at 240V)
Flow rate: Minimum of 18 GPM is required
Applicable Standard
Ul 1563 Fifth ed.
CSA No. 22.2 - 218.1-M89
Electrical specifications UL CSA:
Voltage Input: 120/240 VAC
Current Input: 2 x 48 A or 1 x 60 A
Master in.xe™
Output Voltage Current
Output 1A Pump 1 (2 speed) High 120/240V 20 FLA/70 LRA
Output 1B Pump 1 (2 speed) Low 120/240V 15 FLA/60 LRA
Output 2 Pump2 (1 speed) 240V 15 FLA/60 LRA
Output 3 Blower 120/240V 6 FLA/10 A
Output 4 Circ Pump 120/240V 6 FLA/10 A
Direct Direct (audio) 120/240V 10 A
L1 Light 12V 1 A
Output 5 Heater 240V 4.0 kW
** The total maximum amperage for blower, circ pump
and Direct cannot exceed 12 Amps
specifications
Slave in.xe™
Output Voltage Current
Output 1A Pump3 (1 speed) 120/240V 10 FLA/60 LRA*
Output 1 B Pump4 (1 speed) 240V 15 FLA/60 LRA
Output 2 Pump5 (1 speed) 120/240V 10 FLA/60 LRA
Output 3 Light 3 120/240V 6 FLA/10 A
Output 4 Ozone 120/240V 6 FLA/10 A
Direct Direct (other) 120/240V 6 FLA/10 A
L1 Light 2 12V 1 A
Output 5 Heater 240V 4.0 kW
* To install pump 5, an in.split™ cable is required. If the pump 5 is not
installed, the pump 3 can be 20 FLA and a two speed pump.
If both pump 3 & pump 5 are installed, then each individual pump
cannot exceed 10 FLA (max total combined of 20 FLA).
** The total maximum amperage for light 3, Ozone and Direct cannot
exceed 12 Amps
