Swim Spa Solution™specifications
heat.wav ratings
Voltage: 230 VAC, 50 Hz
Current: 8.7 A resistive (2 kW at 230V)
5.7 A resistive (1.3 kW at 230V)
16 A resistive (3.8 kW at 230V)
Flow rate: Minimum of 18 GPM is required
Electrical specifications TUV:
Voltage Input: 230/400 VAC 3 phase or single
Current Input: 3 x 20 A max or 1 x 60 A
Master in.xe™
Output Voltage Current
Output 1A Pump 1 (2 speed) 230V 15 FLA/60 LRA
Output 1B Pump 1 (2 speed) 230V 15 FLA/60 LRA
Output 2A Pump 2 (1 speed) 230V 15 FLA/60 LRA
Output 3 Blower 230V 6 FLA/10 A
Output 4 Circ Pump 230V 6 FLA/10 A
Direct Direct (audio) 230V 10 A
L1 Light 12V 1 A
Output 5 Heater 230V 3.8 kW
** The total maximum amperage for blower, circ pump
and Direct cannot exceed 12 Amps
Slave in.xe™
Output Voltage Current
Output 1A Pump 3 (1 speed) 230V 7.5 FLA/60 LRA*
Output 1B Pump 4 (1 speed) 230V 15 FLA/60 LRA
Output 2 Pump 5 (1 speed) 230V 7.5 FLA/60 LRA
Output 3 Light 3 230V 6 FLA/10 A
Output 4 Ozone 230V 6 FLA/10 A
Direct Direct (other) 230V 6 FLA/10 A
L1 Light 2 12V 1 A
Output 5 Heater 230V 3.8 kW
* To install pump 5, an in.split™ cable is required. If the pump 5 is not
installed, the pump 3 can be 15 FLA and a two speed pump. If both
pump 3 & pump 5 are installed, each individual pump cannot
exceed 7.5 FLA (max total combined of 15 FLA).
** The total maximum amperage for light 3, Ozone and Direct cannot
exceed 12 Amps
Applicable Standard
European:
EN/IEC 60335-1: 2002/2001
EN/IEC 60335-2-60: 2003/2002 (incl. Corr. & Am up to 2004)
EN55014-1, EN55014-2
EN61000-3-2, EN61000-3-3
Australia:
AS/NZS 3136:2001 +A1 +A2
AS/NZS 3100:2002 + A1+A2+A3
