43
Swim Spa Solution™
IPx5 level of waterproofing is conditional on 3 items:
• Both front covers (heater and input wiring) are closed and
screwed shut.
• A suitable waterproof strain-relief/bushing is used for the cable
entry into the pack.
• Any unused in.link™ connection (HC, LC, or low voltage) is plugged
with the appropriate blank plug.
The in.xe.ce™ is lab tested to IPx5 enclosure protection levels.
Environmental:
• Operating temperature: 0 °C (32 °F) to 50 °C (122 °F)
• Storage temperature: -20°C (-4°F) to 85°C (185°F)
• Humidity: up to 85% RH, non condensing
• Water ingress protection: IPx5
Mechanical:
Weight: 4.76 kg (10.5 lbs)
Dimensions (W x H x D):
Chassis: 441.5 x 298.5 x 129 mm (17.38" x 11.75" x 5.1")
specifications
