MC-MP-SBD O wner’s Manual
12
18
3/8
"
467 mm
13
5/16
"
338 mm
4
1/4
"
108 mm
Spa Pack Overall Dimensions
15
3/4
"
400 mm
The cover of the MC-MP-SBD power box can easily be
removed. Simply loosen the 4 front cover screws to access
connectors and jumpers. Remove the plastic cover to access
main board.
Removable Cover
Warning:
Mounting feet
Heater
Specifications
Any physical damage to the enclosure arising from misuse, abuse
or improper installation will automatically void any liability of the
product.
