MC-MP-SBD O wner’s Manual
25
Certain system operating parameters can be configured from the keypad. This is
normally done by Spa Builders or the spa installer, but may be done any time.
Low Level Programming
7- Circulation pump
Display: CP x
Value of x: 0 = not installed
1 = regulated (with spa
temperature)
2 = always on
3 = on, except if 2 degrees
over set point
8-
Filter cycle
Display: FC x
Value of x: 1 = filter cycle enabled
2 = filter cycle replaced
by purge cycle
9- Pressure switch status
Display: PS x
Value of x: 0 = with Pump 1
1 = with circ. pump
(CP cannot be set to 0)
10- Timeout output
Display: To x
Value of x: 0 = 20 minutes
1 = 30 minutes
2 = 40 minutes
11-
Current Ratings
Value of x:
C1 x = Select Pump 1 current (1-15A)
C2 x = Select Pump 2 current (1-15A)
C3 x = Select Pump 3 current (1-15A)
Cb x = Select blower current (1- 8 A)
CHx= Select Heater current (12-23A)
Low level programming
To access low level programming, press and hold On/Off key for 20 seconds,
the first parameter's code should appear on the display.
Use Up/Down keys to modify parameter values and On/Off key to change
from one parameter to the next. You must go through all parameters to
exit this mode. If you do not wish to change a parameter, simply press
On/Off key to advance to the next parameter.
List of parameter configurations
1- Pump 1
Display: P1 x
Value of x: 1 = single-speed
2 = two-speed
2- Pump 2
Display: P2 x
Value of x: 0 = not installed
1 = single-speed
2 = two-speed
3-
Pump 3
Display: P3 x
Value of x: 0 = not installed
1 = installed
4-
Blower
Display: bL x
Value of x: 0 = not installed
1 = single-speed
2 = two-speed
3 = three-speed
5-
Light
Display: LI x
Value of x: 0 = not installed
1 = 12 VAC (single-intensity)
2 = 12 VAC (triple-intensity)
3 = 120 VAC (single-intensity
on auxiliary 1 relay )
4 = Internal fiber box control
mode (2-aux. relay)
6-
Ozone
Display: O 3 x
Value of x: 0 = not installed
1 = on only in filter cycle
2 = always on
3 = on with circ. pump
To Next Page
