128 ADV200 • Functions description and parameters list

1 Inp1=Inp2

2 Inp1!=Inp2

3 Inp1<Inp2

4 Inp1>Inp2

5 |Inp1|=|Inp2|

6 |Inp1|!=|Inp2|

7 |Inp1|<|Inp2|

8 |Inp1|>|Inp2|

If set to 0 the comparator is not enabled

If set to 1 the comparator output is enabled when the value of Comparedigitalinp1 is inside the window

resulting from the value of Comparedigitalinp2 ± the tolerance set via the ComparatorWindow.

If set to 2 the comparator output is enabled when the value of Comparedigitalinp1 is not inside the window

resulting from the value of Comparedigitalinp2 ± the tolerance set via the ComparatorWindow.

If set to 3 the comparator output is enabled when Compareinput1is less than Compareinput2.

If set to 4 the comparator output is enabled when Compareinput1is greater than Compareinput2.

If set to 5 the comparator output is enabled when the value of Comparedigitalinp1 is inside the window

resulting from the absolute value of Comparedigitalinp2 ± the tolerance set via the ComparatorWindow.

If set to 6 the comparator output is enabled when the absolute value of Comparedigitalinp1 is not inside the

window resulting from the absolute value of Comparedigitalinp2 ± the tolerance set via the Comparator

Window.

If set to 7 the comparator output is enabled when the absolute value of Comparedigitalinp1 is less than the

absolute value of Comparedigitalinp2.

If set to 8 the comparator output is enabled when the absolute value of Digitalcomparinp1 is more than the

absolute value of Digitalcomparin2.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

22.10.6 3672Comparewindow perc FLOAT 0.0 0.0 100.0 ERW FVS

Setting of the tolerance window for comparing the Compareinput1 and Compareinput2 signals.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

22.10.7 3674Comparedelay s FLOAT 0.0 0.0 30.0 ERW FVS

Setting of the delay for signalling the result of the comparison.

Menu PAR Description UM Type FB BIT Def Min Max Acc Mod

22.10.8 3676Compareoutput BIT 16 0 0 1 ER FVS

The status of the comparator output is displayed:

0 The result of the set comparison is negative

1 The result of the set comparison is positive
