16 ADV200 • Functions description and parameters list
520 Enc 3 (EXP-SESC-I1R1F2-ADV)
776 Enc 4 (EXP-EN/SSI-I1R1F2-ADV)
1032 Enc 5 (EXP-HIP-I1R1F2-ADV)
2056 Enc 7 (EXP-HIP-I1R1F2-ADV)
4 Can/Dnet (EXP-DE-I1R1F2-ADV)
4 Can/Dnet
260 Probus
516 RTE
576 FastLink
320 I/O Ext
832 I/O FastLink
255 Unknown
2312 Enc 8 (EXP-ASC-I1-ADV)
1288 Enc 6 (EXP-RES-I1R1-ADV)
5633 I/O 6 (EXP-IO-SENS-1000-ADV)
6401 I/O 7 (EXP-IO-D5R8-ADV)
7681 I/O 8 (EXP-IO-SENS-100-ADV)
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.18 546 Fwencsl2ver.rel UINT16 0 0 0 R FVS
The version and release number of the rmware installed on the encoder (mounted in slot 2) used in the drive
are displayed. When the parameter is read via serial line or eldbus the version is returned in the high byte and
the release in the low byte.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.19 548 Fwencsl2type UINT16 0 0 0 R FVS
The version of rmware on the encoder card mounted in slot 2 is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.20 5300Fwencsl1-3ver.rel UINT16 0 0 0 R FVS
The version and release number of the rmware on the encoder card (mounted in slot 1 or 3) used in the drive
are displayed. When the parameter is read via serial line or eldbus the version is returned in the high byte and
the release in the low byte.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2.21 5302Fwencsl1-3type UINT16 0 0 0 R FVS
The version of rmware on the encoder card mounted in slot 1 or 3 is displayed.
Menu PAR Descrizione UM Tipo FB BIT Def Min Max Acc Mod
2.22 5724FwFastLinkver.rel UINT16 0 0 0 ER FVS
The version and release number of the FastLink card rmware installed in the driveare displayed.
When the parameter is read via serial line or eldbus the version is returned in the high byte and the release in
the low byte.
Menu PAR Descrizione UM Tipo FB BIT Def Min Max Acc Mod
2.23 5726FwFastLinktype UINT16 0 0 0 ER FVS
The type of FastLink card rmware installed in the drive is displayed.
