gefran ADV200

ADV200 • Parameters List 227
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5.15 640 Dig speed ref 1 FF INT16 16/32 0 CALCI CALCI ERW FVS
5.16 642 Dig speed ref 2 FF INT16 16/32 0 CALCI CALCI ERW FVS
5.17 650 Speed ref 1 src LINK 16/32 640 0 16384 ERW FVS
L_MLTREF
5.18 652 Speed ref 2 src LINK 16/32 642 0 16384 ERW FVS
L_MLTREF
5.19 654 Speed ref invert src LINK 16 6000 0 16384 ERWZ FVS
L_DIGSEL2
5.20 660 Speed ref 1 mon FF INT16 0 0 0 ER FVS
5.21 662 Speed ref 2 mon FF INT16 0 0 0 ER FVS
5.22 670 Speed ref top lim FF INT32 CALCI 0 CALCI ERWZ FVS
5.23 672 Speed ref bottom lim FF INT32 CALCI CALCI 0 ERWZ FVS
5.24 666 Speed ref filter ms UINT16 0 0 1000 ERWZ FVS
5.25 680 Full scale speed rpm INT16 CALCI 50 32000 RWZ FVS
5.26 222 Theta ref src LINK 16/32 220 0 16384 ERW F_S
L_MLTREF
5.27 226 Flux ref src LINK 16/32 224 0 16384 ERW F_S
L_MLTREF
6-RAMPS
6.1 700 Acceleration time 0 s FLOAT 10.0 0.01 1000.0 RW FVS
6.2 702 Deceleration time 0 s FLOAT 10.0 0.01 1000.0 RW FVS
6.3 704 Acceleration time 1 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.4 706 Deceleration time 1 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.5 708 Acceleration time 2 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.6 710 Deceleration time 2 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.7 712 Acceleration time 3 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.8 714 Deceleration time 3 s FLOAT 10.0 0.01 1000.0 ERW FVS
6.9 720 Ramp type ENUM Linear 0 3 ERWZ FVS
0 Linear
1 S-Shape
2 Bypass
3 Off
6.10 722 Multi ramp sel 0 src LINK 16BIT 6000 0 16384 ERW FVS
L_DIGSEL2
6.11 724 Multi ramp sel 1 src LINK 16BIT 6000 0 16384 ERW FVS
L_DIGSEL2
6.12 726 Multi ramp sel mon UINT16 0 0 3 ER FVS
6.13 730 Accel jerk time 0 s FLOAT 1.0 0.02 10.0 ERW FVS
6.14 732 Decel jerk time 0 s FLOAT 1.0 0.02 10.0 ERW FVS
6.15 734 Accel jerk time 1 s FLOAT 1.0 0.02 10.0 ERW FVS
6.16 736 Decel jerk time 1 s FLOAT 1.0 0.02 10.0 ERW FVS
6.17 738 Accel jerk time 2 s FLOAT 1.0 0.02 10.0 ERW FVS
6.18 740 Decel jerk time 2 s FLOAT 1.0 0.02 10.0 ERW FVS
6.19 742 Accel jerk time 3 s FLOAT 1.0 0.02 10.0 ERW FVS
6.20 744 Decel jerk time 3 s FLOAT 1.0 0.02 10.0 ERW FVS
6.21 750 Ramp in zero src LINK 16BIT 6000 0 16384 ERW FVS
L_DIGSEL2
6.22 752 Ramp out zero src LINK 16BIT 6000 0 16384 ERW FVS
L_DIGSEL2
6.23 754 Ramp freeze src LINK 16BIT 3480 0 16384 ERW FVS
L_DIGSEL2
