gefran ADV200 Functions Description And Parameters List

54 ADV200 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.17 1042FRforwardsrc LINK 16 1112 0 16384 ERW FVS
Selection of the origin (source) for the FR forwardstart signal. With this command the motor starts to rotate
(with the Enable command enabled). The terminal to be associated with this function can be selected from the
“L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.18 1044FRreversesrc LINK 16 1114 0 16384 ERW FVS
Selection of the origin (source) for the FR reverse signal. With this command the motor reverses the direc-
tion of rotation (with the Enable command enabled). The terminal to be associated with this function can be
selected from the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.19 1046FR*stopsrc LINK 16 6000 0 16384 ERW FVS
Selection of the origin (source) for the FR stop signal. The terminal to be associated with this function can be
selected from the “L_DIGSEL2” selection list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.20 1048FRstartmon BIT 16 0 0 1 ER FVS
The status of the Start output of the ForwardReverseControl(FRC) block is displayed.
0 Stop
1 Start
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.21 1050FRreversemon BIT 16 0 0 1 ER FVS
The status of the Reverse output of the ForwardReverseControl(FRC) block is displayed.
0 No Reverse
1 Reverse
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.22 1052FRcdmmon UINT16 0 0 0 ER FVS
The status of the commands of the ForwardReverseControl(FRC)block are displayed.
FR*stopsrc FRreversesrc FRforwardsrc FRcdmmon
0 0 0 0
0 0 1 1
0 1 0 2
0 1 1 3
1 0 0 4
1 0 1 5
1 1 0 6
1 1 1 7
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
11.23 1032DrvInterlocksrc LINK 16 6002 0 16384 ERW FVS
This parameter is used to select the origin (source) of the Drv Interlock signal.
The signal to be associated with this function can be selected from the “L_DIGSEL2” selection list.
0 Drive interlock active (Drive disabled)
1 Drive interlock not active (Drive can be enabled)
