R-Series v5 Instruction Manual36
© 2018 Geist
GM1196 R-Series v5 Instruction Manual
2. Sensors, System, and Help Tabs
· Mouse over to show sub-menus:
Table 3-1 Sensors, System, and Help Tabs
3. Log In / Log Out
· Click to log in or log out of the unit. Note that both user-name and password are
case sensitive; prohibited characters are: $&`:<>[ ] { }"+%@/ ; =?\^|~',
4. Alarms and Warnings
· Indicates the number of Alarms and Warnings currently occurring, if any.
5. Device Label
· Displays the user-assigned label of this unit (see "Configuration and Operation")
6. Device ID
· Unique product identification. May be required for technical support.
7. Total and Individual Phase or Line Monitor
· Displays AC current, voltage, and power statistics for each individual phase, phase
pair, and for the total of all phases combined.
8. Line Current
· Displays AC line current draw for 3-phase Delta PDUs.
9. Circuit and Outlet
· Displays AC current, voltage and power statistics for each circuit and outlet. (Outlet
Level Power Monitoring and Switched Outlet Level Monitoring Only)
· Displays outlet status. (Switched and Switched Outlet Level Monitoring Only)
