3030 mFlow
20.3 Order data separate fi tting
Housing material Code
1.4435 stainless steel 41
Seal material Code
Without (only housing configuration KH, KF) 00
FPM (only housing configuration KD, KU, KN) 4
EPDM (only housing configuration KU, KN) 14
Order example
3030 000 KH WS 41 00 -
Type 3030
Nominal size (code) 000
Housing configuration (code) KH
Connection (code) WS
Housing material (code) 41
Seal material (code) 00
K-Number (code) -
Connection Code
GEMÜ weldolet (only housing configuration KH) WS
Union end with insert (threaded socket Rp) 7R
DIN wafer-type flange (only housing configuration KF) 8
Butt weld spigot DIN 11850 series 2
(only housing configuration KU, KN) 17
Housing configuration Code
GEMÜ in-line housing KD
GEMÜ wafer-type flange KF
GEMÜ weldolet KH
Neumo BioControl
®
in-line housing KN
Tuchenhagen Varivent
®
in-line housing KU
K-Number Code
Ra  0.8 m electropolished (internal/external)
surface finish data refer to medium wetted surfaces
(only housing configuration DU, DN) 1503
20.4 Order data Connection kit
Connections X1*and X3*, A-coded Code
without connector socket, with M12 cap 0000
M12 socket, A-coded, angle, without cable,
screw terminal 00M0
M12 socket, B-coded, angle, can be shielded,
M12 plug, B coded, angle, can be shielded,
for Profibus DP DPM0
M12 socket, A-coded, angle,
with 5 m cable, 0.34 mm² PUR cable 05M0
M12 socket, A-coded, angle,
with 10 m cable, 0.34 mm² PUR cable 10M0
Field bus Code
Connection kit S02
Accessory Code
Accessory Z
Order example
3030 S02 Z 00M0 00M0
Type 3030
Field bus (code) S02
Accessory (code) Z
Connection X1 and X3*, A-coded (code) 00M0
Connection X2**, B-coded (code) 00M0
* X1 and X3 with Profibus DP version: B-coded
** X2 with Profibus DP version: A-coded
Connection X2**, B-coded Code
without connector socket, with M12 caps 0000
M12 socket, B-coded, angle, without cable,
screw terminal 00M0
M12 socket, A-coded, angle,
without cable for Profibus DP DPM0
Y cable + 1 x M12 socket, B-coded, angle,
without cable, screw terminal 00Y0
Y cable + M12 socket, B-coded, angle,
with 10 m cable, 0.34 mm² PUR cable
10 m Sub-D connecting cable 10Y0
Y cable + M12 socket, B-coded, angle,
with 10 m cable, 0.34 mm² PUR cable
10 m Sub-D connecting cable 10Y0
