Gema OptiSpray DPP01 - Optispray DPP01 - Connections; Pin Assignment

V 03/13
OptiSpray DPP01 Start-up and operation • 15
OptiSpray DPP01 - connections
Pin assignment
Power IN connection
1 Neutral conductor N
2 Phase (100-240 VAC) P
3 empty
PE Grounding PE
Control IN socket, 12 pins
A-J Control signal
K IDENT / Recognition
L REQUEST / Request
M GND
Enclosure - shield
2
PE
3
1
