34 • Spare parts list OptiSpray DPP01
OptiSpray DPP01 - spare parts list
OptiSpray DPP01 Dense phase pump - complete
1005 823
OptiSpray DPP01 Dense phase pump (HF version) - complete
1005 822
Filter ring bush - complete (pos. 2, 3, 4, 5)
1004 832
2
Filter ring bush
1004 699
3
Filter ring
1004 696#
4
O-ring - Ø 32x2 mm
1005 930#
5
O-ring - Ø 19x1.5 mm
1005 749#
13
Pinch valve body
1004 694
15
Y-piece
1004 698
16
O-ring - Ø 3x1 mm
1000 377#
17
Hose connection – 4.5 mm
1005 474
18
O-ring - Ø 8x1.5 mm
248 878#
19
Washer - Ø 6.4/11x1.6 mm
1005 254
20
Allen cylinder screw - M6x20 mm
216 429
21
Nut with kink protection - M12x1 mm, Ø 8 mm
201 316
22
Powder hose suction side - Ø 4.5 mm (not shown)
1005 454*
23
Maintenance set 1 – 2 x filter elements 3 µm, complete
1005 257
24
Maintenance set 2 – 8 x pinch valves with Short instructions (not shown)
1005 256
25
Hose connection - 7 mm
1005 596
26
Nut with kink protection - M16x1 mm
1005 443
27
Powder hose transport side - Ø 11.5/7 mm (not shown)
1005 097*
28 Assembly tool for powder chamber connection fitting (not shown) 1005 058
* Please indicate length
# Wearing part
