Cinterion
®
Java Terminals Hardware Interface Description
8.3 Configuration via ASC0 Interface
69
EHSxT_BGS5T_HID_v02 2014-05-23
Confidential / Preliminary
Page 64 of 70
8.3.1.11 Configure ADC1_IN/DSR0/SPI_CLK Line
This command configures the the ADC/DSR0/SPI_CLK signal on the Weidmueller connector
to be either an analog input line (ADC) or a digital output line (DSR0/SPI_CLK). If configured
as analog input, the signal is connected to the Java module‘s ADC1_IN line. If configured as
digital output, the signal is connected to the Java module‘s DSR0/SPI_CLK line that can be
configured to be either DSR0 or SPI_CLK (SPI_CLK not available for BGS5T USB).
Note: If configuring the ADC1_IN/DSR0/SPI_CLK line please take great care to be in accor-
dance with the Java module‘s current configuration of the ADC1_IN and DSR0/SPI_CLK sig-
nals.
Command ADC_DSR0
Parameter <input/output>
Type Boolean
Range 0: Analog input (ADC1_IN)
1: Digital output (DSR0/SPI_CLK)
Default 0: Analog input (ADC1_IN)
Non-volatile Yes
Example WD= ADC_DSR0,0,0 // Configures the line to be analog input
WD= ADC_DSR0,1,1 // Configures the line to be digital output
