第 13 页 共 16 页
Parameter
High byte
Parameter
Low byte
Default Rang Comment
8 50 1 - 999 Clamp /Wiper revert time ms
9 0
0／1
Thread Clamp function：
0：off 1：on
A 100 0 - 359 Clamp start angle
B 210 0 - 359 Clamp end angle
1 0
0／1
The automatic test mode selection ：
0: order stitches 1: order time
2 300 0 ~1000
The safety SW alarm confirm time ms(the same
way does not distinguish between direct-drive
safety SW and flat lock trim of protection SW)
3 50 0 ~1000 The safety SW restore confirm time ms
Stop mode
3
4 0
0／1
Motor rotation direction setup：
1：Forward 0：Reverse
motor/machine head run rate: 0.001
0 1000 0 - 9999
(if automatic calculation of motor/machine head run
rate has done, the Parameter value in control box
maybe different with that in HMI)
2 0 0 - 359
Up needle position adjusted angle（compare to up
position sensor position excursion）
3 175 0 - 359 Down needle position mechanical angle
Machine head
parameter
4
4 1 1- 800 Press down delay time(ms)
2.4 HMI version number and its parameter modified mode
During HMI idle, Press key, then press key, HMI entry display version number interface, such
as see picture . HMI return to idle if press or no press the key after
regulate time.
After HMI entry display version number interface, if press key, then press key, HMI can entry
