Parameter
High byte
Parameter
Low byte
Default Rang Comment
4 180 10 -359
The end angles of trimming（relative down
position of angle, Need to greater than the system
of parameters【03】）
5 10 1 -999
Trimming start delay time T1（ms）
6 60 1 -999
Trimming end delay time T2（ms）
0 0
0／1／2
／3／4
Mode selection for tension-release sequence:
0:According to the parameters [11] set angles is
tension release, until up position delayed [14] time
off.
1：According to the parameters【11】set angles is
tension release, until【12】set angles off.
2：According to the parameters【11】set angles is
tension release, it delayed 【14】off.
3：Down position signal delayed the parameter【13】
set angles is trimming, it delayed 【14】off.
4: Up position signal delayed the parameter【13】
set angles is trimming, it delayed 【14】off.
1
25
5 -359
The start angles of tension release(r e l a t i v e
d o w n position of angle)
2
300
10 -359
The end angles of tension release
（relative
d o w n position of angle,
Need to greater than
the system of parameters【11】）
3
1
1 - 999
Tension release solenoid start delay timeT1（ms）
4
10
1 - 999
Tension release solenoid up position delay time T2
（ms）
5
1
0／1
selection for Wiper function
0：off 1：on
6
10
1 - 999 Clamp /Wiper delay time ms
Tension
release 、
Wiper and
Clamp mode
1
7
30
1 - 9999 Clamp /Wiper holding time ms
