4.2 Wireless Receiver: URX-P40
The receiver is plugged into the LRAD and relays audio sent from the transmitter to be
broadcast through the LRAD.
The following figure highlights the different interfaces located on the receiver.
The receiver connects directly to the LRAD. The receiver is powered by the LRAD and does not
require batteries.
*There are two types of receivers: one that has a POWER switch, and one that does not. Your
receiver will depend on your LRAD. Note how power is controlled on your LRAD.
• If your LRAD does not have a POWER switch, then you will need a receiver with a
POWER switch.
• If your LRAD has a POWER switch, then you will need a receiver without a POWER
switch.
POWER
Switch
(Conditional)*
Figure 5: Wireless Receiver
SELECTION
Buttons
SYNC
Button
Audio
Cable
SET Button
