Manual Part No.: 119514-00 Rev. 03
• Make sure that the channel group and channel number, and therefore the frequency
(displayed at the bottom of the GP/CH menu), match exactly on both the transmitter and
the receiver.
• If the channel group and channel number match, the transmitter and receiver should
successfully connect.
• If the the transmitter and receiver are connected, black bars will appear on the right side of
the screen (as seen in Figures 9, 10, and 11).
o These bars display the A and B tuner signal strength meters. The Wireless Kit will
always transmit broadcasts using the strongest of the two signals.
o Also on this screen are the audio level (top-left) and the battery level (top-right).
• If the channel group and channel number match but the transmitter and receiver do not
connect, cycle the transmitter’s power (turn the transmitter off and back on). This should
connect the two devices.
7.2 Clear Channel Scan
Along with manually choosing the desired channel, users also have the option of performing a
clear channel scan.
By initiating a clear channel scan, the user is tasking the receiver to scan for the best available
channel in a given channel group. The scan seeks out the quietest channel in order to ensure
audio is relayed clearly from the transmitter to the receiver.
To initiate a clear channel scan, perform the steps listed on the following page.
NOTE: The desired channel group must already be selected before performing the clear channel
scan.
