5.1 Belt Pouch Use
The belt pouch allows the user to secure the transmitter to their waist, freeing up their hands
for more flexibility while operating the Wireless Kit. The belt pouch is designed to fit tightly
around the transmitter.
To use the belt pouch, perform the following steps.
1. Unsnap the pouch’s strap and position the pouch with the buckle facing the user.
2. Insert the bottom-left corner of the transmitter into the pouch first, so that the ALERT TONE
button fits through the opening on the left side of the pouch (Figure 7).
3. Pull the right side of the pouch up over the bottom-right corner of the transmitter until fully
seated. Snap the pouch’s strap into place (Figure 8).
4. Slide belt pouch onto the user’s belt through the loop on the back of the pouch.
Figure 7: Transmitter Partially in Belt Pouch
Figure 8: Transmitter Completely in Belt Pouch
