10
609.6mm [24.0"]
917mm [36.1"]
254mm [10.0"]
60.7mm [2.4"]
794mm [31.3"]
59.8mm [2.4"]487mm [19.2"]
TRIPLE EKO SUITABLE
FOR 1", 1.25" & 1.50" CONDUIT
3 PLACES
ĵ62.7 (2.47")
2" EKO
PADLOCK
(CUSTOMER SUPPLIED)
LOCATION
ĵ14mm [ĵ0.6"]
ĵ8mm [ĵ0.3"]
7.48mm [0.3"]
4.02mm [0.2"]
Installation Diagram Drawing No. 0K2436-A
