Specifications
6 Owner’s Manual for Stationary Diesel Generators
Specifications
Engine
A complete specification sheet is included in the documentation provided with the unit at the time of purchase. For
additional copies, consult your local Independent Authorized Service Dealer (IASD).
General 2.5L Engine 2.2L Engine
Engine System
Type 4 cylinder, in-line, 4 cycle 4 cylinder, in-line, 4 cycle
Fuel Type Ultra Low Sulfur Diesel Ultra Low Sulfur Diesel
Fuel Filtering 6 Microns 25 Microns (maximum)
Bore and Stroke 3.30 in x 3.90 in (84 mm x 100 mm) 3.30 in x 3.90 in (84 mm x 100 mm)
Displacement 152.86 cubic inches (2.505 liter) 135.2 cubic inches (2.216 liter)
Firing Order 1-3-4-2 1-3-4-2
Direction or Rotation CCW - As Viewed From Flywheel CCW - As Viewed From Flywheel
Dimensions L x W x H
615 mm x 492 mm x 623 mm
(24.21 in x 19.37 in x 24.53 in)
662 mm x 489 mm x 698 mm
(26.1 in x 19.3 in x 27.5 in)
Dry Weight 375 lb (170 kg) 507.1 lb (230 kg)
Compression Ratio 22: 1 21.3 : 1
Cooling System
Water Pump Pre-Lubed, Self-Sealing Pre-Lubed, Self-Sealing
Drive Belt Belt
Thermostat
Full Open Temperature:
170 F (76.5° C)
Full Open Temperature:
180° F (82° C)
System Coolant Capacity 3.0 gal (11.44 liter) 2.5 gal (9.5 liter)
Coolant Flow Rate 17 gal (65 liter)/min at 1800 RPM 14.8 gal (56.2 liter)/min at 1800 RPM
Lubricating System
Oil Pump Type Gear Gear
Oil Filter Type Full Flow Spin-On Canister Full Flow Spin-On Canister
Oil Cooler Not Applicable Installed
Crankcase Capacity 6.87 qt. (6.5 liter) 11.2 qt. (10.6 liter)
Lubricating Oil 15W-40 15W-40
Oil Fill Location Filler Cap on Valve Cover and/or Front Engine Cover Filler Cap on Valve Cover and/or Front Engine Cover
Oil Drain Location Oil Pan, Bottom Side Oil Pan, Bottom Side
Intake and Exhaust System
Intake Air System Naturally Aspirated Turbocharged / Aftercooled
Maximum Allowable
Intake Restriction
7.87 in. of Water (1.96 kPa) 20 in. of Water (5.0 kPa)
Maximum Allowable
Exhaust Back Pressure
26.8 in. of Water (6.67 kPa) 41 in. of Water (10.2 kPa)
Breather Closed Crankcase System Open Crankcase System
Other Specifications
Operating Temperature Range -20° F to 120° F (-29° C to 49° C) -20° F to 120° F (-29° C to 49° C)
POWER ADJUSTMENT FOR AMBIENT CONDITIONS
Temperature Deration3% for every 5 °C above 25 °C or 1.7% for every 5 °F above 77 °F
Altitude Deration (15 & 30 kW)1% for every 100 m above 915 m or 3% for every 1000 ft above 3000 ft
Altitude Deration (20 kW) 1% for every 100 m above 305 m or 3% for every 1000 ft above 1000 ft
