Use batterychargerplugto keepthe battery chargedand ready
for use. Batterychargingshouldbe done in a dry location.
1. Plugcharger into "Battery ChargerInput"jack, locatedon the
control panel.Plug wall receptacleend of the battery charger
into a 120 VoltACwalt outlet.
2. Unplugbattery chargerfrom walt outletand control paneljack
whengeneratoris goingto be in use.
NOTE:
Donot usethebattery chargerfor morethan48 hoursat one
charge.
3.1 MAINTENANCESCHEDULE
Follow the calendar intervals. More frequent service is required
whenoperatingin adverseconditionsnoted below.
CheckOil Level
ChangeOil and OilFilter:!:
CleanSparkArrestor Screen
ServiceAir Filter
ReplaceSparkPlug
$
"k
At EachUse
*Every Season/Every100 Hours
**Every Season/Every100 Hours
**Every Season/Every200 Hours
EverySeason
Changeoil after first 30 hours of operationthen every season.
Changeoil and oil filter every month when operatingunder heavy load or in
high temperatures.
Cleanmore often under dirty or dusty operating conditions. Replaceair filter
parts if very dirty.
3.2 PRODUCTSPECIFICATIONS
3.2.1 GENERATORSPEC/F/CATIONS
Model # ...................................................................... 005800, 005747
RatedMax. Power................................................................... 8.0 kW**
Surge Power................................................................................ 10 kW
RatedACVoltage...................................................................... 120/240
RatedMax AC Load
Current@ 240V............................................................. 33.3 Amps**
Current@ 120V............................................................. 66.7 Amps**
RatedFrequency.................................................... 60 Hz@ 3600 RPM
Phase................................................................................ SinglePhase
RatedDCVoltage...................................................................... 12 Volts
BatteryType.................................................................... 10 AH, 12VDC
Model # ...................................................................... 005797, 005798
RatedMax. Power................................................................... 7.0 kW**
Surge Power............................................................................. 8.75 kW
RatedACVoltage...................................................................... 120/240
RatedMax ACLoad
Current@ 240V............................................................. 29.2 Amps**
Current@ 120V............................................................. 58.3 Amps**
RatedFrequency.................................................... 60 Hz@ 3600 RPM
Phase................................................................................ SinglePhase
RatedDCVoltage...................................................................... 12 Volts
BatteryType.................................................................... 10 AH, 12VDC
Model# .................................................................................... 005796
RatedMax. Power................................................................... 6.5 kW**
Surge Power............................................................................. 8.13 kW
RatedACVoltage...................................................................... 120/240
RatedMax ACLoad
Current@ 240V............................................................. 27.1 Amps**
Current@ 120V............................................................. 54.2 Amps**
RatedFrequency.................................................... 60 Hz@ 3600 RPM
Phase................................................................................ SinglePhase
RatedDCVoltage...................................................................... 12 Volts
** Maximumwattageandcurrentaresubjectto,andlimitedby,suchfactors
asfuelBtucontent,ambienttemperature,altitude,enginecondition,etc..
Maximumpowerdecreasesabout3.5%for each1,000feetabovesealevel;
andwillalsodecreaseabout1%for each6° C(10° F)above16° C(60° F)
ambienttemperature.
3.2.2 ENGINESPEC/F/CATiONS
RatedHorsepower@ 3600 RPM.................................................... 14.5
Displacement............................................................................... 410cc
SparkPlugType................................... ChampionRC14YCor Equivalent
SparkPlug PartNo.................................................................... 0E7585
SparkPlug Gap............................................... 0.030 inch or (0.76 mm)
GasolineCapacity............................................................ 9 U.S. gallons
OilType.................................... SeeChart in "Adding EngineOil"Section
OilCapacity................................................ w/Filter Change= 1.5 Qts.
w/o FilterChange= 1.2 Qts.
Oil FilterPart No...................................................................... 070185B
RunTime/FuelConsumption-l/2 Load.. 10 Hours/ .73 gallons per hour
Class IIEmissionCertified
3.2.3 EMISSIONS/NFORMATiON
The EnvironmentalProtection Agency (EPA) requires that this
generatorcomplywith exhaustandevaporativeemissionstandards.
This generator is certified to meet the applicable EPAemission
levelson gasoline.Theemission control systemon this generator
consists ofthe following:
• FuelSystem • Air InductionSystem
Carburetor - IntakePipe/manifold
FuelTank!cap - AirFilter
FuelLines * IgnitionSystem
EvaporativeVentLines _ Sparkplug
ExhaustSystem - Ignitionmodule
ExhaustManifold • ExhaustSystem
Muffler _ ExhaustManifold
It is importantto perform the service specifiedin the Maintenance
Scheduleto ensurethatthe generatorcomplies with the applicable
emissionstandardsfor the duration of its useful life. Additionally,
emissions critical maintenancemust be performed as scheduled
in orderfor the EmissionsWarrantyto be valid. Emissionscritical
maintenanceconsists of servicing the air filter and spark plugs in
accordancewith the MaintenanceSchedule.Service and repairs
may be performedby any capableperson or repairshop.
12
