PARTS LIST – #40-125

NOTES:

PART NO. REF. N0. DESCRIPTION SPECIFICATIONS QTY

40125-01 60800001A ALUMINUM CARRIAGE BRACKET 1

40125-02 60500002 MAIN GEAR SHAFT 1

40125-03 60500003 LEAD SCREW 4

40125-04 60100017 INSERT RING 1-1/2” 1

40125-05 60500005 GEAR SHAFT 4

40125-06 60800021 CARRIAGE PLATE 4

40125-07 60800004 CLAMP POST 1

40125-08 60800007A TOP PLATE 1

40125-08A 60700031 STARTING PIN 1

40125-08B 906M06025 PHILLIPS HEAD SCREW M6 X 25 1

40125-09 60500009 CAM GEAR 1

40125-10 60700010 ELLIPTICAL WHEEL 1

40125-11 912M14000 NYLON NUT M14 1

40125-12 60500012 GEAR SPROCKET 5

40125-13 60700017 LOCK GUIDE NUT 1

40125-14 60700002 UPPER GUIDE NUT BASE 1

40125-15 914M061301 FLAT WASHER M6 8

40125-16 9140381902 FLAT WASHER M10 3

40125-17 60700009 LIFT CRANK HANDLE 1

40125-18 60800005 SLEEVE 3

40125-19 60800018 SCALE PLATE 1

40125-20 908M06006 SET SCREW M6 X 6 9

40125-21 60800002 BUSHING 4

40125-22 9236805Z0 BEARING 6805ZZ 5

40125-23 901M08020 CAP SCREW M8 X 20 1

40125-24 903M06018 FLAT HEX SOCKET HEAD SCREW M6 X 18 8

40125-25 903M04012 FLAT HEX SOCKET HEAD SCREW M4 X 12 2

40125-26 9180404018A KEY M4 X 4 X 12 5

40125-27 9236804Z0 BEARING 6804ZZ 5

40125-28 60700009B CRANK HANDLE SLEEVE 1

40125-29 9236900Z0 BEARING 6900ZZ 3

40125-30 903M06030 FLAT HEX SOCKET HEAD SCREW M6 X 30 2

40125-31 60800020 CHAIN 1

40125-32 919S01000 C-RING S10 2

40125-33 912M06000 NYLON NUT M6 4

40125-34 60100018 INSERT WRENCH 1

40125-35 60800003 BACK LASH LOCK 1

40125-36 901M10070A CAP SCREW M10 X 70 3

40125-37 910M10005 HEX NUT M10 2

40125-38 901M06060A CAP SCREW M6 X 60 4

40125-39 901M10055 CAP SCREW M10 X 55 1

40125-40 94300002 O-RING 12.42 X 1.78 1
