37
PART NO. REF. NO. DESCRIPTION SPECIFICATIONS QTY
40130-01 32240001 FRONT BOX PANEL 1
40130-02 32240002 RIGHT BOX PANEL 1
40130-03 PHILLIPS HEAD SCREW
28
40130-04 PHILLIPS HEAD SCREW
40130-05 32240003 HINGE 1
40130-06 32240004 LEFT BOX PANEL 1
40130-07 32240005 REAR BOX PANEL 1
40130-08 32240006 POWER CORD CLAMP 2
40130-09 32240007 BOTTOM BOX PANEL 1
40130-10 32240008 VENT BASE 1
40130-11 32240009 VENT ADJUSTMENT PLATE 1
40130-12 920040100 RIVET M3.2 5
40130-13 AIR HOSE (FENCE SIZE 35”)
1
40130-14 32240010 DOOR PANEL 1
40130-15
904M06012 HEX BOLT M6
X 12 6
40130-16 915M06000 LOCK WASHER M6 6
40130-17 914M061301 FLAT WASHER M6 6
40130-18 32240011 MAGNET 1
40130-19 32240012 DUST OUTLET 1
40130-20 HOSE CLAMP 2
PARTS LIST – #40-130
Dust Collection Kit
(#40-130)
