- 31 -
2. Brake pad worn out 2. Brake pad worn out
3. Improper installation of brake pad 3. Improper installation of brake pad
4. Brake pad polluted
Strange sound in braking
1. Brake pad worn out
2. Brake pad polluted
1.3 Front hydraulic brake
* Note
•The braking components can not be spoiled by oil stain
in installation or disassembly.
•Rinse with stipulated cleaning agent in order to avoid
reduction of braking quality.
Disassemble the front wheel spindle.
Unload the front wheel.
1.3.1 Disassembly
*Note
•Always replace the brake pad in pairs.
•If a brake pad is reused, mark a signal
on its side before disassembly so that it
can be installed to the original position.
Disassemble the brake cylinder set from the left shock
absorber and take out the brake pad from the brake cylinder
set.
Front brake syste
