9-17
09
Motor compartment
(if equipped)
ORG3EV091029
1. Remove the cover covering the cabin
air filter by pushing out the retainer
clip with a slim tool.
2. Press and hold the lock on the left side
of the cover and then pull the cover
out.
3. Replace the cabin air filter.
4. Reassemble in the reverse order of
disassembly.
NOTICE
OHI078055
Install a new cabin air filter in the
correct direction with the arrow symbol
ƢIDFLQJGRZQZDUGVWRSUHYHQWQRLVH
and reduce effectiveness.
