Instrument panel fuse panel
Fuse Name
Fuse Rating Circuit Protected
Module 9
10A
Overhead Console, AMP, A/V & Navigation Head Unit,
Driver/Passenger Power Seat Module, Inverter (Rear),
Rear Seat LH/RH Heater Unit, Electro Chromic Mirror,
Rear Seat Console Remote Control Switch, SDC,
Smart Phone Wireless Charger, Data Link Connector
Module 11
10A
Head Lamp LH/RH, ADAS Unit (Parking),
Multifunction Switch
Module12
10A IAU, IBU
A/C3
10A
A/C Control Module, Front A/C Controller,
Rear A/C Controller
A/BAG IND.
10A Instrument Cluster, Overhead Console
E-Shifter2
10A Electronic ATM Shift Dial
Spare
15A Not Used
Module 10
10A ICU Junction Block (ESU)
Module 7
10A
Driver Door Module, Stop Lamp Switch, IBU, IAU,
Multifunction Switch
Multi Media
25A A/V & Navigation Head Unit
Module 13
10A
ICU Junction Block (ESU), A/C Control Module,
Front A/C Controller, Rear A/C Controller,
Instrument Cluster, Head-Up Display, Security Indicator
Cluster
10A Instrument Cluster, Head-Up Display
IBU 2
10A IBU
Airbag 2
15A
SRS Control Module, Passenger Occupant Detection
Sensor
Presafety Seat
Belt 3
10A Pre-Active Seat Belt Unit
Module8
10A
Rear Corner Radar LH/RH, ECS Unit, Crash Pad Switch,
ADAS Unit (Driving), ADAS Unit (Parking), Front View
Camera, Front Console Switch, Steering Tilt & Telescopic
Unit
Spare
10A Not Used
Module3
10A
Rear Corner Radar LH/RH, Front Console Keyboard,
Rear Seat Console Remote Control Switch, VESS Unit,
Steering Tilt & Telescopic Unit, Front Corner Radar LH/RH,
Smart Phone Wireless Charger, Clock Spring
