9-
39
09
Fuse/R
elay P
anel Description
Instrument panel fuse panel
OJWEV091013
Inside the fuse/rela
y box cov
er
, you can
find the fuse/rela
y label describing fuse/
rela
y names and ratings.
Information
Not all fuse panel descriptions in this
manual may be applicable to your vehicle;
the information is accurate at the time of
printing. When you inspect the fuse box on
your vehicle, r
efer to the fuse box label.
OJWEV091023N
665
667
