Instrument cluster
Information
Detailed information on 3D instrument cluster is provided later in this chapter.
8-inch8-inch
12.3-inch 3D12.3-inch 3D
The actual cluster in the vehicle may differ from the illustration.
For more information, refer to “Gauges and metres” section in this chapter.
OJX1040001E/OJX1040002EOJX1040001E/OJX1040002E
1. Tachometer
2. Speedometer
3. Engine coolant temperature gauge
4. Fuel gauge
5. Warning and indicator lights
6. LCD display
INSTRUMENT CLUSTER
