09
9-49
Dashboard fuse panel
Fuse Name
Symbol
Fuse
Rating
Circuit Protected
POWER
OUTLET2
POWER
OUTLET
2
20A Front Console Power Outlet
P/SEAT DRV2
2 DRV
25A Driver Power Seat Module
P/SEAT PASS1
1 PASS
25A Passenger Power Seat Module
S/HEATER
DRV
FRT
15A Driver Power Seat Module
S/HEATER
PASS
PASS
15A Passenger Power Seat Module
DOOR LOCK
20A Door Lock/Unlock Relay
SPARE(B+)
SPAER
(B+)
10A Not Used
MODULE6
MODULE
6
10A
DVRS Unit, Armrest Lamp, IBU, Low DC-DC
Converter, Electronic ATM Shift Lever Dial, Front
Tray Lamp, Front Console Keyboard, A/V &
Navigation Head Unit, Rear USB Charger, ADAS
Unit (Parking), AMP, MTS E-Call Switch, MTS E-Call
Module, IAU, Low DC-DC Converter (AMP)
BRAKE
SWITCH
BRAKE
SWITCH
10A Stop Lamp Switch, IBU
