Genicom LA36N - Page 14

1-10
2. Push both gray ribbon release tabs 1 so that they snap into the cartridge and the ribbon
feed mechanism 2 moves to the FREE position (according to markings).
Releasing the Ribbon Feed Mechanism
3. Turn the ribbon feed knob 4 clockwise (according to the engraved arrow) to be sure that
the ribbon 3 feeds properly.
Tightening the Ribbon
1
2
4
