Step Description
1. Set up the laser in the pipe at the front side.
2. Align the cross axis using the electronic level vial shown in the display.
3. For Zeta125s: Wait until the electronic level vial moves to the middle
position. The cross axis is aligned automatically.
4. Place the target at the opposite side of the pipe. Align the target with
the level vial.
5. Adjust the line direction using the remote control. Refer to "Keys".
6. Move the pipe to the correct height and direction. When the beam is
in the target sign the pipe is in the desired slope.
GeoMax_Zeta125_Zeta125s_UM_v1.0.0_en.fm Page 36 Friday, November 28, 2014 9:23 AM
