Product Overview Zeta125/ Zeta125s | 35
EN
Use with standard, fixed target
Use the same base feet extensions for the laser and the target plate.
Use with universal target
Step Description
1. Adjust the target plate to the pipe diameter.
2. Move the target plate in the base until the mark is on the line of the
feet length mounted at the laser.
3. Tighten the target plate in place.
150 mm
diameter:
200 mm
diameter:
008398_001
008399_001
