38
2.6 GV-AS110 Specifications
CPU 32-bit RISC microprocessor
Number of User Cards
1,000 / 40,000 cards (standalone / networked or RS-
485 mode)
Event Buffer 65,536 events and log data
Power 100 ~ 240V AC, 50 ~ 60Hz
1 Wiegand interface, 26 ~ 64 bit format
Wiegand Interface
12V DC Power Supply, 200mA
Communication Protocol RS-485
Input 3 inputs, dry contact, NO / NC
Digital I/O
Output 2 outputs
Operating Temperature -20 ~ 60°C / -4 ~ 140°F
Operating Humidity 10% ~ 90% RH (non-condensing)
Dimensions (W X H X D) 95 x 108 x 23mm / 3.74 x 4.25 x 0.91 in
Weight 200 g / 0.44 Ib
Certification IP54, CE, FCC, RoHS
