GV-AS400 Controller
81
3
3.7 GV-AS400 Specifications
CPU 8-bit RISC microprocessor
Number of User Cards 40,000 cards
Event Buffer 65,536 events and log data
Power 100~250V AC, 50~60Hz
RS-485 Interface
1 RS-485 interface only for GV-Readers and GV-GF
Fingerprint Readers (max. 8 readers)
8 Wiegand interfaces, 26 ~ 64 bit format
Wiegand Interface
12V DC power supply, 200mA
Communication TCP/IP
Input 16 inputs, dry contact, NO / NC
Output
8 relay outputs
8 photo relay outputs
Operating Temperature 0 ~ 65°C / 32 ~ 149°F
Operating Humidity 10% ~ 90% RH (non-condensing)
Dimensions of GV-AS400 Board
(W X H X D)
210 x 170 x 30 mm / 8.27 x 6.69 x 1.18 in
Weight 400 g / 14.11 Ib
Certification CE, FCC, RoHS
