Installation 11
Note: If a plotter is already installed in the PLOTTER port on the
GRAPHIX ADVANTAGE, use the TABLET port to install a second
plotter.
Communication Parameters
If you are connecting the GS750
plus
to a system other than the
GRAPHIX ADVANTAGE, the plotter uses these RS-232
communication parameters:
Communication
Parameters
9600 Baud
No Parity
8DataBits
1StopBit
Xon/Xoff Flow Control
The plotter has a 25DB female connector with these pin
assignments:
Pin Signal
2Tx
3Rx
4RTS
5CTS
7SigGnd
All other pins are not connected.
