38 GS750
plus
Front Panel
The GS750
plus
front panel keys shown below are used to perform
all of the following operations:
! Position the carriage and material.
! Put the plotter on-line for drawing, cutting, and pouncing.
! Select single or continuous job processing.
! Select knife mode.
! Initialize the knife tool.
! Access diagnostic modes, as needed. See the
Special
Diagnostics
and
Error Conditions
sections for more
information.
A further explanation of key functions and several test exercises
follow.
RESET
RUN
CONT
RUN
SINGLE
SWIVEL
KNIFE
SLOW
INIT
KNIFE
POWER
