24 -
INSTRUMENTS
Unloading side
Recorder
See recorder operating instructions in the TECHNICAL MANUAL
chapter Components.
Operator.s control panel
Learn the function of the control panel by studying chapter Control unit
PACS 3500.
Emergency stop
See chapter Introduction, “Safety devices, an overview”.
1. Recorder for temperature and
pressure.
3. Operator’s control panel
2. Pressure gauge chamber pressure. 4. Emergency stop.
