101
Field Description
IP Address Enter the IP address that you allow to access.
Protocol Select the protocol that you allow to access.
You may select TCP, UDP or TCP&UDP.
Port Range Enter the port range that you allow to access.
Comment Enter the comment about the virtual server.
Current Virtual Servers in System
The figure above shows the current virtual server in the system.
5.6.3 DMZ
DMZ allows all the ports of a PC on your LAN to be exposed to the Internet. Set the IP
address of the PC to be DMZ host, so that the DMZ host will not be blocked by
firewall.
Click Firewall > DMZ to display the DMZ Settings page.
The parameters of DMZ settings are described as follows:
