Mounting the door transmission cable (optional)8.8
Loosen bolts (27).
X
Remove the cover (28) for the side element.
X
Break out the breaking point (29) in the cover (28).
X
Unscrew the nut (31) at the door transmission cable (30).
X
Thread the door transmission cable (30) through the cover (28).
X
Screw the nut (31) tight in the cover (28).
X
Loosen the strain relief (33).
X
Loosen the screw (34) and pull o the protective conductor.
X
Loosen the cable at the terminal strip (35).
X
Remove the power plug (32) with cable.
X
