Mounting dimensions for the types of mounting8.2
Transom mounting hinge side with guide rail8.2.1
Fixing with mounting plate Direct xing
Dimensional reference hinge middle14
Cable entry for power supply cable15
Cable entry for control cables16
Observe drilling template: DIN left and DIN right mirrored.
X
Fastening means
Mounting plate M5 à
Base plate M5 or chip board screws à
Guide rail M5 or chip board screws à
Take drive orientation into account: Motor towards hinge.
X
Required space
ECturn required space17
Dimensional reference top edge door prole = Top 18
edge guide rail
Required space for guide rail19
