GEZE ECturn Mounting Instructions

ECturn
21
Maintenance
Maintenance10
The following prescribed maintenance work at the ECturn must be carried out at least once a year by properly
trained personnel.
Dangers during mechanical service10.1
WARNING!
Danger of fatal injury via electric shock!
Disconnect the power supply from the drive by a disconnecting device supplied by the customer and secure it
X
against reactivating.
WARNING!
Danger of injury through crushing!
When working on the drive ensure that you cannot be injured by swing movements of the lever or of the link
X
arm.
WARNING!
Danger of getting burnt through hot motor!
The motor in the drive can have relatively high temperatures after continuous operation or poor ease of move-
ment or other defects.
If necessary, switch o the power supply and rst let the motor cool down before carrying out work.
X
Maintenance work10.2
The ECturn is free of maintenance to a great extent. The following work has to be carried out during mainte-
nance:
Inspect fastening screws for rm seating.
X
Tighten the fastening screw for the link arm or roller lever.
X
Clean the inside of the roller guide rail.
X
Check that the door latch functions correctly and is clean, oil lightly if necessary.
X
Check the roller lever or the link arm for damage, replace if necessary.
X
Carrying out a manual trial run
Requirements:
The drive has been disconnected at all poles from the power supply.
Ensure that the door moves properly.
X
Check that the mounting is correct.
X
Switch the power supply back on or plug the power plug back on.
X
Electrical servicing10.3
Keep the test documents up-to-date and make them available. à
With DPS: In the menu item à
sa
query
the number of openings ( à
co
),
the operating hours ( à
ho
) and
service ( à
so
) and document them in the maintenance manual.
After completing the maintenance work, always execute the Learning function for the ECturn (see Section à
10.2).
Check the functioning of the actuating and presence sensors and replace if necessary. à
Direct querying of the controller using S1, S2: à
Refer to the wiring diagram, Commissioning and servicing chapter as well as Parameter menu service LEDs à
and display programme switch chapter.
